ZLA-25L Semi-automatic Auger filling machine
Descriptive abstract
This type can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder, wheat flour, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals, powder additive, talcum powder, agriculture pesticide, dyestuff, and so on.
主要特點
Stainless steel structure；Quick disconnecting or split hopper could be washed easily without tools.
Servo motor drive screw.
PLC & touch screen make it be easy of operation.
重量反饋和比例跟踪擺脫了不同材料的不同比例的可變包裝重量的不足。
Save the parameter of different filling weight for different materials. To save 10 sets at most
Replacing the auger parts, it is suitable for material from super thin powder to granule.
Main Technical DatA
| Hopper | Quick disconnecting hopper 25L |
| 包裝重量 | 10 - 1000g |
| 包裝精度 | ≤ 100g,≤±2%; 100 – 500g, ≤±1%; ≥500g,≤±0.5% |
| 填充速度 | 5 – 20 times per min |
| 電源 | 3P AC208-415V 50/60Hz |
| 總功率 | 2.25Kw |
| 總重量 | 350公斤 |
| Overall Dimensions | 1205×1010×2174mm |
